Ground Screw
share
Specification sheet for hot dip galvanized screw ground anchor
Detail
Specification sheet for hot dip galvanized screw ground anchor
Length: | 600-4000mm |
Out diameter: | 48mm,60mm,68mm,76mm,89mm,100mm,115mm |
Pipe thickness | 2.5mm,3mm,3.5mm,3.75mm,4mm |
Material | Q235, Q195 |
Surface treatment | Hot dip galvanized or black-selfcolor |
Top style | Flange (Round flange,Square flange or U flange),Nuts with bolts only |
Over 30 Ground Screw Combinations
We have a range of over 30 ground screws,combining different lengths and
diameters with several head configurations,to suit hundreds of different
products application.
